SC APC LC UPC Duplex Single mode G657A or customized Fiber Optic Patch cord

SC APC LC UPC Duplex Single mode G657A or customized Fiber Optic Patch cord

SC APC LC UPC Duplex Single mode G657A or customized Fiber Optic Patch cord
Listed as an SC APC to LC UPC duplex single-mode G657A patch cord — but the photo shows an orange SC–SC duplex cord instead. Read the note before ordering.
- General Details
- TESTING PERFORMANCE
On paper, this is a duplex single-mode patch cord to G657A, SC APC on one end and LC UPC on the other, with 1310 nm and 1550 nm test wavelengths, insertion loss ≤0.20 dB typical (≤0.30 max), return loss ≥50 dB, and 1,000 mating cycles. It is rated -20 to +70 °C working and -40 to +85 °C storage, with ISO9001, ROHS and CE certification, and it is listed for CATV, telecom, LAN/WAN and active device use.
That is what the title and the specification lines say. The photo says something else — see below.
Key details
- Model: SC APC LC UPC
- Type (as listed): duplex single-mode patch cord, G657A
- Connectors (as listed): SC APC to LC UPC
- Test wavelengths: 1310 nm, 1550 nm
- Insertion loss: ≤0.20 dB typical, ≤0.30 max; return loss ≥50 dB
- Durability: 1,000 mating cycles
- Length: not stated — confirm before ordering
Please read before ordering
The photo on this page does not match the title. It shows a coiled orange duplex cable with cream/beige SC connectors on both ends — SC–SC, multimode in appearance, with no LC connector and no green APC connector visible anywhere. A single-mode SC APC to LC UPC cord should be a yellow cable with a green APC connector on one end. This page also lists the fiber material as PMMA (plastic, 650 nm) in one place and single-mode G657A glass (1310/1550 nm) in another — those two cannot both be true. The main category is “Multimode Fiber” while the title says single mode. Do not order this product on the strength of the photo or the title alone; confirm the connector types, the fiber type and the length with us first.
Related: SC–SC multimode quartz fiber jumper, LC–SC yellow single-mode fiber jumper, Orange SC–SC glass fiber patch cord. See more cable assemblies at BH Cables.
