OPTICAL FIBER CABLES

Optical fiber Cable:

Optical fiber cable consists of two parts. The center is called the core, the

outer layer is called the cladding. The refractive index of the core is higher

than that of the cladding. The effect of this arrangement is that when an

optical ray is propagated at an angle to the axis of the cable, it is reflected

back at the boundary between the core and the cladding, and thereby

transmitted longitudinally through the core.

There are three kinds of optical fiber:

a) All-plastic fiber (APF)

b) Plastic-cladding silica Fiber (PCF)

c) Silica fiber

APF is used for short-distance data transmission. Both the core and the

cladding are made of plastic. PCF, which is used for middle distance

transmission, has silica core and plastic cladding.Silica fiber is used for longdistance transmission. Both the core and the cladding are made of silica.

TOSLINK devices can be classified as follows:

Optical Modules:

Gerneral Purpose: Simplex(JIS F05) and Duplex (JIS F07), for APF and PCF.

Medium Speed Data Transmission: Simplex(JIS F05) and Duplex (JIS F07), for APF and PCF.

Ceramic Package Modules: Simplex(JIS F05) and Duplex (JIS F07, PN), for APF and PCF.

High Speed Data Transmission: Duplex (SMI, PN), for APF.

Digital Audio: Simples (JEITA RC-5720 square style), For APF

it has TOSLINK Optical Fiber Cable used on Factory automation(FA), digital audio, car audio and navigation system, audio video fields, Interface Station, Optical fiberless communications, CNC, Electrical and optical transmission system. Fiber-Optic Devices TOSLINK include TOSHIBA

Fiber-Optic Connectors for Optical Fiber Cable:

Simplex(F05) and Duplex(F07), Snap in and Clip, for APF and PCF.

Connectors for Optical Fiber Cable:

Simplex(F05) and Duplex(F07), Snap in and Clip, for APF and PCF.

Optical Fiber Cables:

Simplex and Duplex for APF and PCF.

Application examples of TOSLINK:

TOSLINK is used in a wide variety of applications, such as digital audio and factory automation.

1, Factory automation (FA);

2, Industry control;

3, For CNC control replacement, CNC controller, Evlevator, server, printed machine

4, Digital audio;

5, Car audio and navigation system;

6, Office automation (OA);

TOCP Optical Fiber Series Cables:
1. F05 Type (simplex)
TOCP100, TOCP100P, TOCP155, TOCP155P. (APF 980/1000).
TOCP100Q, TOCP100X, TOCP150Q, TOCP150X (PCF 200/300) Toshiba TOCP optical fiber cables.

2, F07 Type (duplex)
TOCP200, TOCP200P, TOCP255, TOCP255P. (APF 980/1000)
TOCP200Q, TOCP200X (PCF200/300) Toshiba Optical Fiber Cables.
** P type and X type are reinforced cable **

3, For Digital Audio Use (simplex)
TOCP172 APF 970/1000.
