Bosch kabel Fiber Optik Crane Kato Fiber Optic Crane Kato For KATO
This is the red fibre optic cable for KATO cranes — a red POF signal lead with silver metal SMA connectors (knurled metal ferrules, red tail sleeves), made for KATO crane SR250V and SS 500 machines. The photo shows the red coil with its silver SMA connector, and the body photos show the red cable with a black corrugated protection sleeve section and a white/grey metal SMA connector in the foreground.
Crane and excavator signal cable lives a hard life, so this lead is built for it: pull-resistant, waterproof, pressure-resistant, low insertion loss, wear and corrosion resistant, with a Toray imported 1.0 mm core, PE/PVC jacket and a 3.65 mm finished diameter. It is non-conductive and immune to EMI, which is exactly what a crane control signal needs. The stated spec is attenuation under 180 dB/km, working temperature −55 to +85 °C, ISO9001 and RoHS listed, for data centres, industrial control, power and home networks as well as crane use.
At a glance
- Red POF cable, silver metal SMA connectors, red tail sleeves
- Toray imported core, 1.0 mm; finished diameter 3.65 mm
- Attenuation <180 dB/km; working temperature −55 to +85 °C
- For KATO crane SR250V / SS 500, and crane / excavator signal use
Please read before ordering: the length is written two ways on this listing — the spec block says 32 m, while the performance specs say a standard length of 1000 mm with 0–100 m custom. Confirm the length you need before ordering. No part number is readable on any label in the photos. (The title mixes in the German words “kabel” and “Optik” — it is the same red crane cable.)
