Television Balun Satellite RJ45 Male to F type Male Adapter Coax Cable (IEC 9.5MM TV Male)

A three-piece balun kit that gets a TV signal from an RJ45 wall outlet to a TV's IEC aerial socket — the F connector sits in the middle, not at the end.

SKU: FEV-BL107 Categories: ,
Television Balun Satellite RJ45 to F type Male Coax Adapter Cable

Television Balun Satellite RJ45 to F type Male Coax Adapter Cable

This one is a kit, not a single cable — three pieces that screw together. Read the title carefully, because the F connector is in the middle of the assembly, not at the end you plug in. The photo shows all three pieces laid out: the white coax in the middle, a small black IEC adapter, and the RJ45 plug.

How it goes together: (1) a balun adapter, RJ45 male to F female; (2) a coax cable, F male to F male; (3) an adapter, F female to IEC 9.52 mm male. Once assembled, the two ends you actually plug in are the RJ45 male and the IEC 9.5 mm male — the RJ45 end goes to the wall outlet, the IEC end goes to the TV. The F connectors join the pieces to each other. The diagram in the photos shows the same thing: the cable ends are male, and the sockets they plug into (RJ45 female, IEC 9.52 mm female, F female) are on the wall and the TV side.

Please read before ordering: two numbers on this page don’t agree, and we left both as they are instead of picking one. The spec table printed in the old text says Part # FEV-BL1002, but the SKU field on this listing says FEV-BL107 — confirm which part number you need before ordering. The sizes disagree too: the French text gives 11.7 x 1.5 x 40 mm (which looks like the adapter body only), while the spec table gives 14.2 x 15.6 x 2000 mm. The 2000 mm is the cable length. The rest of the spec table is copied below exactly as printed.

Key facts

  • Product: television balun satellite adapter coax cable, RJ45 male to F type male (IEC 9.5 mm TV male)
  • Model / SKU: FEV-BL107 (spec table in the old text prints Part # FEV-BL1002 — see the note above)
  • Kit: 3 pieces — RJ45 male / F female adapter + F male / F male coax + F female / IEC 9.52 mm male adapter
  • Ends you plug in: RJ45 male + IEC 9.5 mm male
  • Length: 2 m, per the spec table dimensions (14.2 x 15.6 x 2000 mm)
  • Type: passive, no external power required; package includes 2 units, a pair
  • Bandwidth: 40 MHz to 2.4 GHz (French text: 5–2400 MHz)
  • 3 dB bandwidth: 40 MHz to 1 GHz; insertion loss <3 dB at 40–1 GHz (French text: <2 dB at 900 MHz, <3 dB at 2.2 GHz)
  • Return loss: >18 dB at 40–1 GHz; CMRR -20 dB or higher at 40 MHz–1 GHz
  • UTP cable: CAT5e/6, 24 AWG, impedance 100Ω
  • Distance: based on frequency or input video signal level, max. up to 100 m; up to 30 m at 2.4 GHz
  • Temperature: operation 0 to 55°C, storage -20 to 85°C, humidity up to 95%
  • Works with: CATV, satellite, VHF, UHF and FM signal over Cat5e cable; CATV splitters, amplifiers and cable modems
F Male Connector RF to RJ45 Balun Adapter Coax Cable with F to IEC Adapter

F Male Connector RF to RJ45 Balun Adapter Coax Cable with F to IEC Adapter

F Male RF Connector to RJ45 CAT5 CAT6 Ethernet Converter Coax Cable with F Female to IEC TV Male Connector

F Male RF Connector to RJ45 CAT5 CAT6 Ethernet Converter Coax Cable with F Female to IEC TV Male Connector

instructions of F Male to RJ45 Balun Coax Cable

Good for

A satellite or TV feed that has to travel over network cable — one adapter at each end of a Cat5e run, with the coax only covering the last stretch to the set.

Specification instruction of 75ohm Coax Cable to Cat5 RJ45 Extender Balun coax cable

Specification instruction of 75ohm Coax Cable to Cat5 RJ45 Extender Balun coax cable
