Cordon Balun passif TV 9.52 mm mâle vers Ethernet RJ-45 mâle Erard Blanc IEC to RJ45

A white passive balun cord — gold IEC 9.52 mm male plug on one end, shielded RJ45 male on the other — for carrying a TV signal over a network cable.

SKU: FEV-BL-1005 Categories: ,
General Details

A white passive balun cord, Erard, for running a TV signal over a network cable. One end is a gold IEC 9.52 mm male plug — round barrel, centre pin clearly visible in the photo — the other is a shielded RJ45 male plug with a black sleeve and a white strain-relief boot. Plug the RJ45 end into the wall outlet, the IEC end into the TV, and the aerial signal travels down the Cat5e in the wall. No power needed.

The coax inside is 75 ohm, shielded — copper core, dielectric, braided shield, outer sheath — with a balun chip doing the impedance matching between the 75 ohm coax side and the 100 ohm network side. It passes DC as well, so it works with satellite setups that send power and switching signals (DC, 22 kHz, DiSEqC) down the line.

Please read before ordering: this page has a few mismatches and we left them all visible instead of smoothing them over. First, the featured image’s file name and alt text both say “F Male”, but the photo shows the round gold IEC 9.5 mm male plug — not a threaded F connector. Go by the photo. Second, the spec table printed in the old text says Part # FEV-BL1002, but the SKU field on this listing says FEV-BL-1005 — confirm which part number you need before ordering. Third, the old French text contradicts itself on warranty: one place says 1 year, another says 15 years under normal use, or 1000 insertions. We can’t tell which one applies, so confirm before ordering. Fourth, the old French text lists lengths of 0.3, 0.5, 2 and 2.5 m as available — this listing doesn’t say which length it ships, so length is not stated, confirm before ordering. The UHF (TNT) use needs an F / IEC adapter, which is not supplied.

Key facts

  • Product: passive TV balun cord, IEC 9.52 mm male to RJ45 male, Erard, white
  • Model / SKU: FEV-BL-1005 (spec table in the old text prints Part # FEV-BL1002 — see the note above)
  • Ends: IEC 9.52 mm male (gold, centre pin visible) + shielded RJ45 male
  • Cable: 75 ohm coaxial, shielded — copper core, dielectric, braid, outer sheath; balun chip
  • Frequency: 50–2200 MHz; max. attenuation in band 6.5 dB
  • DC passing: passes DC signals, 22 kHz, DiSEqC
  • Use it for: satellite reception, UHF (TNT) with an F / IEC adapter (not supplied), cable distribution (wide band)
  • Type: passive, no external power required
  • Length: not stated — confirm before ordering
  • Warranty: the old text says 1 year in one place and 15 years / 1000 insertions in another — confirm before ordering
F Male Connector RF to RJ45 Balun Adapter Coax Cable with F to IEC Adapter

F Male Connector RF to RJ45 Balun Adapter Coax Cable with F to IEC Adapter

F Male RF Connector to RJ45 CAT5 CAT6 Ethernet Converter Coax Cable with F Female to IEC TV Male Connector

F Male RF Connector to RJ45 CAT5 CAT6 Ethernet Converter Coax Cable with F Female to IEC TV Male Connector

instructions of F Male to RJ45 Balun Coax Cable

Good for

A white TV setup where the aerial point is an RJ45 wall socket — the cord matches white skirting and wall plates better than a black cable, and the gold IEC plug is the standard fit for a TV aerial socket.

Specification instruction of 75ohm Coax Cable to Cat5 RJ45 Extender Balun coax cable

Specification instruction of 75ohm Coax Cable to Cat5 RJ45 Extender Balun coax cable
